詳細描述
[[[[[[[[[[[[[[[[[[[[[[[產品參數, 參數]]]]]]]]]]]]]]]]]]]]]]]
產品型號 | 刃經Dc(mm) | 炳徑Ds(mm) | 總長L(mm) | 槽長L3(mm) | 最大鉆削深度L4(mm) |
HZ-SFP205N-0300 | 3.00 | 4 | 66 | 26 | 21 |
HZ-SFP205N-0317 | 3.17 | 4 | 66 | 26 | 21 |
HZ-SFP205N-0330 | 3.30 | 4 | 66 | 26 | 21 |
HZ-SFP205N-0350 | 3.50 | 4 | 66 | 26 | 21 |
HZ-SFP205N-0357 | 3.57 | 4 | 66 | 26 | 21 |
HZ-SFP205N-0370 | 3.70 | 4 | 66 | 26 | 21 |
HZ-SFP205N-0380 | 3.80 | 4 | 74 | 27 | 27 |
HZ-SFP205N-0397 | 3.97 | 4 | 74 | 27 | 27 |
HZ-SFP205N-0400 | 4.00 | 4 | 74 | 27 | 27 |
HZ-SFP205N-0420 | 4.20 | 6 | 74 | 27 | 27 |
HZ-SFP205N-0437 | 4.37 | 6 | 74 | 27 | 27 |
HZ-SFP205N-0450 | 4.50 | 6 | 74 | 27 | 27 |
HZ-SFP205N-0460 | 4.60 | 6 | 74 | 27 | 27 |
HZ-SFP205N-0465 | 4.65 | 6 | 74 | 27 | 27 |
HZ-SFP205N-0476 | 4.76 | 6 | 74 | 27 | 27 |
HZ-SFP205N-0480 | 4.80 | 6 | 82 | 32 | 32 |
HZ-SFP205N-0500 | 5.00 | 6 | 82 | 32 | 32 |
HZ-SFP205N-0516 | 5.16 | 6 | 82 | 32 | 32 |
HZ-SFP205N-0550 | 5.50 | 6 | 82 | 32 | 32 |
HZ-SFP205N-0555 | 5.55 | 6 | 82 | 32 | 32 |
HZ-SFP205N-0556 | 5.56 | 6 | 82 | 32 | 32 |
HZ-SFP205N-0570 | 5.70 | 6 | 82 | 32 | 32 |
HZ-SFP205N-0580 | 5.80 | 6 | 82 | 32 | 32 |
HZ-SFP205N-0595 | 5.95 | 6 | 82 | 32 | 32 |
HZ-SFP205N-0600 | 6.00 | 6 | 82 | 32 | 32 |
HZ-SFP205N-0635 | 6.35 | 8 | 91 | 35 | 35 |
HZ-SFP205N-0650 | 6.50 | 8 | 91 | 35 | 35 |
HZ-SFP205N-0675 | 6.75 | 8 | 91 | 35 | 35 |
HZ-SFP205N-0680 | 6.80 | 8 | 91 | 40 | 40 |
HZ-SFP205N-0700 | 7.00 | 8 | 91 | 40 | 40 |
HZ-SFP205N-0710 | 7.10 | 8 | 91 | 40 | 40 |
HZ-SFP205N-0740 | 7.40 | 8 | 91 | 40 | 40 |
HZ-SFP205N-0750 | 7.50 | 8 | 91 | 40 | 40 |
HZ-SFP205N-0754 | 7.54 | 8 | 91 | 42 | 42 |
HZ-SFP205N-0780 | 7.80 | 8 | 91 | 42 | 42 |
HZ-SFP205N-0794 | 7.94 | 8 | 91 | 42 | 42 |
HZ-SFP205N-0800 | 8.00 | 8 | 91 | 42 | 42 |
HZ-SFP205N-0833 | 8.33 | 10 | 103 | 42 | 42 |
HZ-SFP205N-0850 | 8.50 | 10 | 103 | 42 | 42 |
HZ-SFP205N-0873 | 8.73 | 10 | 103 | 45 | 45 |
HZ-SFP205N-0880 | 8.80 | 10 | 103 | 45 | 45 |
HZ-SFP205N-0900 | 9.00 | 10 | 103 | 61 | 45 |
HZ-SFP205N-0913 | 9.13 | 10 | 103 | 61 | 45 |
HZ-SFP205N-0925 | 9.25 | 10 | 103 | 61 | 45 |
HZ-SFP205N-0930 | 9.30 | 10 | 103 | 61 | 45 |
HZ-SFP205N-0950 | 9.50 | 10 | 103 | 61 | 45 |
HZ-SFP205N-0952 | 9.52 | 10 | 103 | 61 | 48 |
HZ-SFP205N-0980 | 9.80 | 10 | 103 | 61 | 48 |
HZ-SFP205N-0992 | 9.92 | 10 | 103 | 61 | 48 |
HZ-SFP205N-1000 | 10.00 | 10 | 103 | 61 | 48 |
HZ-SFP205N-1020 | 10.20 | 12 | 118 | 71 | 48 |
HZ-SFP205N-1032 | 10.32 | 12 | 118 | 71 | 48 |
HZ-SFP205N-1050 | 10.50 | 12 | 118 | 71 | 48 |
HZ-SFP205N-1070 | 10.70 | 12 | 118 | 71 | 56 |
HZ-SFP205N-1100 | 11.00 | 12 | 118 | 71 | 56 |
HZ-SFP205N-1111 | 11.11 | 12 | 118 | 71 | 56 |
HZ-SFP205N-1120 | 11.20 | 12 | 118 | 71 | 56 |
HZ-SFP205N-1150 | 11.50 | 12 | 118 | 71 | 56 |
HZ-SFP205N-1170 | 11.70 | 12 | 118 | 71 | 56 |
HZ-SFP205N-1191 | 11.91 | 12 | 118 | 71 | 56 |
HZ-SFP205N-1200 | 12.00 | 12 | 118 | 71 | 56 |
HZ-SFP205N-1250 | 12.50 | 14 | 124 | 77 | 56 |
HZ-SFP205N-1270 | 12.70 | 14 | 124 | 77 | 56 |
HZ-SFP205N-1300 | 13.00 | 14 | 124 | 77 | 56 |
HZ-SFP205N-1350 | 13.50 | 14 | 124 | 77 | 59 |
HZ-SFP205N-1370 | 13.70 | 14 | 124 | 77 | 59 |
HZ-SFP205N-1400 | 14.00 | 14 | 124 | 77 | 59 |
HZ-SFP205N-1429 | 14.29 | 16 | 133 | 83 | 60 |
HZ-SFP205N-1450 | 14.50 | 16 | 133 | 83 | 60 |
HZ-SFP205N-1470 | 14.70 | 16 | 133 | 83 | 60 |
HZ-SFP205N-1500 | 15.00 | 16 | 133 | 83 | 60 |
HZ-SFP205N-1550 | 15.50 | 16 | 133 | 83 | 62 |
HZ-SFP205N-1570 | 15.70 | 16 | 133 | 83 | 62 |
HZ-SFP205N-1600 | 16.00 | 16 | 133 | 83 | 62 |
HZ-SFP205N-1650 | 16.50 | 16 | 133 | 93 | 64 |
HZ-SFP205N-1700 | 17.00 | 18 | 143 | 93 | 64 |
HZ-SFP205N-1750 | 17.50 | 18 | 143 | 93 | 66 |
HZ-SFP205N-1800 | 18.00 | 18 | 143 | 93 | 66 |
HZ-SFP205N-1850 | 18.50 | 20 | 153 | 101 | 71 |
HZ-SFP205N-1900 | 19.00 | 20 | 153 | 101 | 71 |
HZ-SFP205N-1950 | 19.50 | 20 | 153 | 101 | 71 |
HZ-SFP205N-2000 | 20.00 | 20 | 153 | 101 | 71 |
